MPT-6 Air Plasma Cutting Machine

Industrial air plasma cutting machine for fast, clean cutting of ferrous and non‑ferrous metals. Uses shop-floor compressed air, with high cutting speed, low operating cost and no heat-affected distortion.

Key Features

• No oxy/fuel required for cutting ferrous & non‑ferrous metals

• Double the cutting speed at roughly half the cost of oxy-fuel

• Minimal heat-affected zone, reduced distortion

• No preheat time or oxygen adjustment needed

• Pilot arc system for easy starts on painted or rusted surfaces

• Electro‑pneumatic protection for low air pressure

• 100% duty cycle at full load current

• Rugged, epoxy powder-coated enclosure

Technical Specifications

• Model: MPT-6

• Primary voltage: 380–440 V, 3‑phase, 50 Hz

• Secondary voltage: 260–280 V

• Line current: 18 A

• Arc current: 40 A

• Open circuit voltage (O.C.V): 300–320 V DC

• Power rating: 12.0 kVA

• Insulation class: F

• Duty cycle: 100% at 40 A

• Cutting capacity (stainless steel, clean cut): 8 mm

• Cutting capacity (stainless steel, parting cut): 12 mm

Contact us for pricing and availability
